CPU (Core/Threads):
|
x86 AMD CPU
|
x86 AMD CPU
|
x86 AMD CPU
|
x86 AMD CPU
|
x86 AMD CPU
|
CPU (Memory):
|
4 GB DDR4
|
4 GB DDR4
|
4 GB DDR4
|
6 GB DDR4
|
8 GB DDR4
|
NPU (Core/Threads):
|
Marvell NPU
|
Marvell NPU
|
Marvell NPU
|
Marvell NPU
|
Marvell NPU
|
NPU (Memory):
|
2 GB DDR4
|
2 GB DDR4
|
4 GB DDR4
|
4 GB DDR4
|
4 GB DDR4
|
Firewall Throughput:
|
3 700 MBit/s
|
7 000 MBit/s
|
7 700 MBit/s
|
10 500 MBit/s
|
11 500 MBit/s
|
Firewall IMIX:
|
2 500 MBit/s
|
2 900 MBit/s
|
3 500 MBit/s
|
4 000 MBit/s
|
4 700 MBit/s
|
Latency (64 byte UDP):
|
6 µs
|
6 µs
|
8 μs
|
8 μs
|
8 μs
|
IPS Throughput:
|
1 015 MBit/s
|
1 355 MBit/s
|
2 000 MBit/s
|
2 600 MBit/s
|
3 300 MBit/s
|
Throughput Threat Protection:
|
240 MBit/s
|
330 MBit/s
|
685 MBit/s
|
900 MBit/s
|
1 000 MBit/s
|
Simultaneous connections:
|
1 600'000
|
1 600'000
|
1 600'000
|
5 000 000
|
6 400 000
|
New connections/sec:
|
35 700
|
44 400
|
61 500
|
69 900
|
74 500
|
IPsec VPN throughput:
|
750 MBit/s
|
900 MBit/s
|
1100 MBit/s
|
1800 MBit/s
|
2500 MBit/s
|
Xstream SSL/TLS Inspection:
|
375 MBit/s
|
420 MBit/s
|
650 MBit/s
|
800 MBit/s
|
950 MBit/s
|
Concurrent connections XStream SSL/TLS:
|
8192
|
8192
|
8192
|
12288
|
18 432
|
Storage (local quarantine/logs):
|
16 GB eMMC
|
Integrated 64 GB SSD
|
Integrated 64 GB SSD
|
Integrated 64 GB SSD
|
Integrated 64 GB SSD
|
Ethernet interfaces (fixed):
|
4 GbE copper, 1 x SFP fiber optic
|
8 GbE copper, 1 x SFP fiber optic
|
8 GbE copper 1 GbE SFP
|
12 GbE copper, 2 x SFP fiber optics
|
10 GbE copper, 2-port 2.5 GbE copper, 2 x SFP fiber
|
Power over Ethernet (min.):
|
-
|
-
|
1 x GbE 803.2at (max. 30 W)
|
2 x GbE (max. 30 W per port)
|
2 x 2.5 GbE (max. 30 W per port)
|
Administrative ports:
|
1 x COM (RJ45), 1 x Micro-USB (cable incl.)
|
1 x COM (RJ45), 1 x Micro-USB (cable incl.)
|
1 x COM (RJ45), 1 x Micro-USB (cable incl.)
|
1 x COM (RJ45), 1 x Micro-USB (cable incl.)
|
1 x COM (RJ45), 1 x Micro-USB (cable incl.)
|
Other I/O ports:
|
1 x USB 2.0 (front), 1 x USB 3.0 (rear)
|
1 x USB 2.0 (front), 1 x USB 3.0 (rear)
|
1 x USB 2.0 (front), 1 x USB 3.0 (rear)
|
1 x USB 2.0 (front), 1 x USB 3.0 (rear)
|
1 x USB 2.0 (front), 1 x USB 3.0 (rear)
|
Number of expansion slots:
|
-
|
-
|
1
|
1
|
1
|
Connection modules (optional):
|
SFP DSL module (VDSL2), SFP transceiver
|
SFP DSL module (VDSL2), SFP transceiver
|
SFP DSL module (VDSL2), 3G/4G module, SFP transceiver
|
SFP DSL module (VDSL2), 3G/4G module, SFP transceiver
|
SFP DSL module (VDSL2), 3G/4G module, SFP transceiver
|
Assembly:
|
Rack mount kit available (must be ordered separately)
|
Rack mount kit available (must be ordered separately)
|
Rack mount kit available (must be ordered separately)
|
Rack mount kit available (must be ordered separately)
|
Rack mount kit available (must be ordered separately)
|
Dimensions width x depth x height:
|
230 x 44 x 205.5 mm
|
230 x 44 x 205.5 mm
|
320 x 44 x 213 mm
|
320 x 44 x 213 mm
|
320 x 44 x 213 mm
|
Weight:
|
1.36 kg (without packing) 2.75 kg (with packing)
|
1.4 kg (without packing), 2.8 kg (with packing)
|
2.2 kg (without packaging) 4.2 kg (with packaging)
|
2.4 kg (without packaging) 4.4 kg (with packaging)
|
2.4 kg (without packaging) 4.4 kg (with packaging)
|
Power supply:
|
External, automatic range adjustment AC-DC 100-240 VAC, 1.7 A@50-60 Hz 12 VDC, 5 A, 60 W
|
External, automatic range adjustment AC-DC 100-240 VAC, 1.7 A@50-60 Hz 12 VDC, 5 A, 60 W Optional second redundant power supply
|
External, automatic range adjustment AC-DC 100-240 VAC, 2.5 A@50-60 Hz 12 VDC, 12.5 A, 150 W Optional second redundant power supply
|
External, automatic range adjustment AC-DC 100-240 VAC, 2.5 A@50-60 Hz 12 VDC, 12.5 A, 150 W Optional second redundant power supply
|
External, automatic range adjustment AC-DC 100-240 VAC, 2.5 A@50-60 Hz 12 VDC, 12.5 A, 150 W Optional second redundant power supply
|
Power consumption:
|
23.2 W/79.16 BTU/h (87) (idle) 43.4 W/148.09 BTU/h (full load)
|
26.1 W/89.06 BTU/h (idle), 53.9 W/183.91 BTU/h (full load)
|
28 W, 96 BTU/h (idle), 57 W/195 BTU/h (full load)
|
30 W/102 BTU/h (idle), 59 W/202 BTU/h (full load)
|
30 W/102 BTU/h (idle), 62 W/212 BTU/h (full load)
|
Incl. Use of PoE:
|
-
|
-
|
38 W/130 BTU/h (full load)
|
76 W/260 BTU/h (full load)
|
76 W/260 BTU/h (full load)
|
Operating temperature:
|
0 °C to 40 °C (operation), -20 to +70 °C (storage)
|
0 °C to 40 °C (operation), -20 to +70 °C (storage)
|
0 °C to 40 °C (operation), -20 to +70 °C (storage)
|
0 °C to 40 °C (operation), -20 to +70 °C (storage)
|
0 °C to 40 °C (operation), -20 to +70 °C (storage)
|
Humidity:
|
10 % to 90 %, non-condensing
|
10 % to 90 %, non-condensing
|
10 % to 90 %, non-condensing
|
10 % to 90 %, non-condensing
|
10 % to 90 %, non-condensing
|
